Tri Axle Trailer for Sale

Tri Axle Trailer for Sale Price: 9800USD

Many customers use Tri Axle Trailer for Sale when shipping containers with low shipping cost and short transit time. Some customers choose bulk carriers or ro-ro ships. Tri Axle Trailer for Sale sprays wax and covers tarpaulin while the cargo ship is in bulk.

Tri axle trailer for sale working platform is the main load-bearing part, which consists of main beam, side beam, beam, bottom plate, suspension and so on. The main beam should pay attention to whether the thickness conforms to international standards. Tri axle trailer for sale main beam international standard is 14/8/16mm.

Tri Axle Trailer for Sale | Tri/ Tripple Axle Flat Deck Trailer for Sale

Tri Axle Trailer for Sale | Tri/ Tripple Axle Flat Deck Trailer for Sale

Tri Axle Trailer for Sale | Tri/ Tripple Axle Flat Deck Trailer for Sale

Specification of Tri Axle Trailer for Sale:

Model: Tri Axle Trailer for Sale

Dimension(mm): 12500x2500x1550mm

Loading capacity(ton): ≤60T

Tire: 12 units, 12.00R22.5 or 315/80R22.5

Rim: 9.00-22.5 or 9.75-22.5

Axles: 3 axles, 13T/16T ,FUWA/ BPW

Suspension: Mechanical suspensionor Air suspension

Spring Leaf: 90(W)mmx13(Thickness)mmx10 layers or 100mmx12mmx12

Valve: WABCO valve (specially intended for oversea market)

King Pin: JOST brand 2.0 or 3.5 inch (bolted or welded)

Landing Gear: JOST brand D200T or Chinese brand 28tons(double-speed)

Main Beam: Height: 500mm, Upper plate:14mm, Middle plate:8mm, Bottom plate:16mm, Material:Q345B steel

Side Beam: 16mm or 18mm steel channel (material: Q235 steel)

Platform: 3mm-thick checkered plate

Brake Chamber: WABCO RE 6 relay valve; T30/30+T30 spring brake chamber(TKL brand), 45L air tank

Twist Locks: 4,8,12 sets (lifting or screw type)

ABS: Optional

Light: LED light (specially intended for oversea market)

Voltage: 24V

Socket(Receptacle): 7-pin Socket (for 7 wire harness)

Tool Box: 1m x 0.5m x 0.5m (The tool box contains 1 tire spanner, 1 gudgeon sleeve and 1 cranking bar. Its size can be tailored to suit your needs)

Painting: Sandblasted, anti-rust chassis surface is available with 1 layer of anticorrosive primer and 2 layers of top coats
