The 40 foot Flatbed Semi Trailer uses an automatic base plate welder. Welding base plate edges are automatically tracked. Just move the torch to the first corner of the base plate and the machine will automatically track and weld all welds without any operator.
3 Axle 40 foot flatbed semi trailer 90# traction pin means that the diameter of the traction pin is 90mm, and the material is mainly chrome alloy. 3 Axle 40 foot flatbed semi trailers are all connected by it. It is connected to the towing seat of the main vehicle and bears all the traction force at the same time. It is an important component.
3 Axle 40 foot Flatbed Semi Trailer for Sale In Zimbabwe
3 Axle 40 foot Flatbed Semi Trailer for Sale In Zimbabwe
3 Axle 40 foot Flatbed Semi Trailer for Sale In Zimbabwe
Model: Tri axle 40 foot flatbed trailer
Dimension(mm): 12500x2500x1550mm
Loading capacity(ton): ≤60T
Axles: 3 axles, 13T/16T ,FUWA/ BPW
Tire: 12 units, 12.00R22.5 or 315/80R22.5
Rim: 9.00-22.5 or 9.75-22.5
Suspension: Mechanical suspension(Germany or America type) or Air suspension(China brand or BPW brand)
Spring Leaf: 90(W)mmx13(Thickness)mmx10 layers or 100mmx12mmx12 (specially intended for overseas markets)
Valve: WABCO valve (specially intended for oversea market)
ABS: Optional
Light: LED light (specially intended for oversea market)
Voltage: 24V
Socket(Receptacle): 7-pin Socket (for 7 wire harness)
Tool Box: 1m x 0.5m x 0.5m (The tool box contains 1 tire spanner, 1 gudgeon sleeve and 1 cranking bar. Its size can be tailored to suit your needs)
Painting: Sandblasted, anti-rust chassis surface is available with 1 layer of anticorrosive primer and 2 layers of top coats
King Pin: JOST brand 2.0 or 3.5 inch (bolted or welded)
Landing Gear: JOST brand D200T or Chinese brand 28tons(double-speed)
Main Beam: Height: 500mm, Upper plate:14mm, Middle plate:8mm, Bottom plate:16mm, Material:Q345B steel
Side Beam: 16mm or 18mm steel channel (material: Q235 steel)
Platform: 3mm-thick checkered plate
Brake Chamber: WABCO RE 6 relay valve; T30/30+T30 spring brake chamber(TKL brand), 45L air tank
Twist Locks: 4,8,12 sets (lifting or screw type)
Fill out the below Email and WhatsApp. We will send you the latest quotation and catalog.
