With many configurations available to choose from the standard Shacman f3000 price to highly specialized vehicles for that tough job, the F3000 has you covered No mate what the job entails, our qualified professionals can help you pick out the perfect vehicle.
Shacman F3000 price mainly from the front axle, rear axle, suspension system, frame and other configurations, the combination of different product configurations, according to the bearing capacity, drive form, will be divided into lightweight, composite version, enhanced version, super version of four version types, can meet different working conditions, different cargo volume user needs.
Under the condition of the same drive, the Shacman F3000 price carrying capacity of the four versions increases from small to large, covering all kinds of transportation requirements from standard load to the total weight of shacman 10 wheeler dump truck
Shacman F3000 10 Wheeler Dump Truck Price - Shacman 10 Wheeler Dump Truck
Shacman F3000 10 Wheeler Dump Truck Price - Shacman Dump Truck
Shacman F3000 10 Wheeler Dump Truck Price - Shacman F3000 Price
Brand: Shacman F3000 10 Wheeler Dump Truck
Truck Model: SX3255DR384R
Drive model: right driven hand, 6X4
Clutch: ∮430 diaphragm clutch
Gearbox Model: Fast Fuller 10JSD180 gearbox with 10 forward and 2 reverse
Propeller shaft: ∮180 contrite gear propeller shaft
Front axle: Man technology 9.5 tons
Rear axle: 16 tons with hub reduction ratio 5.92
Chassis: 850mm
Rear suspension: inverted leaf spring
Instrument panel: Combined instrument panel
Tyre: 12.00R20/12R22.5,11ps
Cabin: Man F3000 flat head with one sleep with A/C, 2 rear windows, mechanical clerestory, hydraulic suspension cab, hydraulic chair, metal bumper, USB, electrically reversal cab
Other: enlargement radiator, ABS
Engine:
Engine model: Weichai WP10.340E22
Power(Kw/Hp): 250/340
Type: diesel engine, 4-stroke,6-cylinder in line, inter-cooling and turbo-charging, euro-II emission standard
Displacement(L):9.726
Steering
Model: integral circuiting ball power steering
Ratio:22.2-26.2:1
Brakes
Running brake: Dual circuiting compressed air brake
Parking brake: Rear wheel power spring brake
Auxiliary brake: Engine exhaust brake
Electrics
Starter: 5.58kw,24V
Alternator: 1.54kw(28V,55A)
Battery: 135AH
Dimension (mm)
Wheel base: 3775+1400
Front-wheel track:1525
Rear wheel track:2036
Front overhang: 1850
Rear overhang: 1450
Approach angle: 28°
Departure angle: 30°
Overall length: 5550
Overall width:2550
Overall height: 3450
Body dimension: 5600X2300X1550 (bottom 8mm and side 6mm)
Fuel tank(L): 380L
Weight(Kg)
GVW:50000
Performance:
Max. running speed(km/h):9 80
Max. climbing capacity(%):20
Min. ground clearance(mm):318
Fuel consumption(L/100km):40
