The new model of Shacman f3000 dump truck has six exclusive fuel-saving technologies, including vehicle power matching, powertrain integration, intelligent thermal management, intelligent shifting, vehicle predictive driving and driving habit evaluation, to provide customers with comprehensive and personalized services. Fuel-saving plan, let fuel consumption "save and save"
Through the coordinated control and dynamic distribution of the Shacman dump truck price power system, the system will intelligently adjust the Shacman dump truck price according to the driving situation whether it is cruising or going up and downhill, whether it is a heavy load or an empty vehicle The driving scene can maintain the most economical and reasonable power output and run faster.
Shacman F3000 Dump Truck | Shacman F3000 Dump Truck Price for Sale In Nigeria
Shacman F3000 Dump Truck Price for Sale In Nigeria | Shacman Dump Truck Price
Shacman F3000 Dump Truck Price for Sale In Nigeria | Shacman Truck Price in Nigeria
Brand: Shacman F3000 Dump Truck
Truck Model: SX3257DR324
Drive model: Left or right driven hand, 6X4
Engine:
Engine model: Weichai WP10.336
Power(Kw/Hp): 247/336
Speed(r/min):2200
Idle speed(r/min):600-800
Max torque(N.m):1250
Type: electrically control, diesel engine, 4-stroke,6-cylinder in line, inter-cooling and turbo-charging, euro-3 emission standard
Stroke(mm):125/147
Displacement(L):9.726
Min.fuel consumption(g/Kw.h):≦198
Engine oil filling volume:39L
Thermostat Opened at 82℃
Oil pump: Bosch
Clutch: ∮430 diaphragm clutch
Gearbox Model: Fast Fuller 9JS135 gearbox with 9 forward and 1 reverse
Propeller shaft: ∮180 contrite gear propeller shaft
Front axle: Man technology 7.5 tons
Rear axle: Styre13 tons with hub reduction ratio 1:4.8
Chassis: Various widths, front 940mm and rear 780mm
Rear suspension: inverted leaf spring with stabilizer
Instrument panel: Combined instrument panel
Tyre: 12.00-20/12.00R20/12.00R22.5,11ps
Cabin: Man F3000 flat head with two seats and one sleep with A/C, 2 rear windows, mechanical clerestory, hydraulic suspension cab, hydraulic chair, metal bumper, USB, electrically reversal cab
Other: enlargement radiator, ABS
Steering
Model: 8098 integral circuiting ball power steering
Ratio:22.2-26.2:1
Brakes
Running brake: Dual circuiting compressed air brake
Parking brake: Rear wheel power spring brake
Auxiliary brake: Engine exhaust brake
Electrics
Starter: 5.58kw,24V
Alternator: 1.54kw(28V,55A)
Battery: 135AH
Dimension (mm)
Wheel base:3200+1350
Front-wheel track:1525
Rear wheel track:2036
Front overhang: 1850
Rear overhang: 1450
Approach angle: 28°
Departure angle: 30°
Overall length: 7550
Overall width:2490
Overall height: 3450
Body dimension:4800X2300X1300/1400/1500(bottom 8mm and side 4mm)
Fuel tank(L): 300L
Weight(Kg)
GVW:25000
Front axle loading capacity:7500
Rear axle loading weight: 13000X2
Performance:
Max. running speed(km/h):90
Max. climbing capacity(%):20
Min. ground clearance(mm):318
Fuel consumption(L/100km):40
